3.3.1.2.5.- SCR
H60 allows one to control those satellite devices that use the SCR protocol, according to the
EN 50494:2006
With the "SLOT ON"-button and whenever we are in SATELLITE-Mode and feeding LNB -
otherwise the equipment will inform us with the appropriate error messages- “
Only Satellite ”
“ No Diseqc. Vdc OFF ” respectively, we get a dropdown menu with the ability to select SCR
channels from SCR 1 to SCR 8. Moving the and pressing key we select the desired
slot, being activated this SLOT SCR.
With the "SLOT OFF"-key and whenever we are in SATELLITE-Mode and feeding LNB -
otherwise the equipment will inform us with the appropriate error messages- “
Only Satellite ”
“ No Diseqc. Vdc OFF ” respectively, we get a dropdown menu with the ability to select SCR
channels from SCR 1 to SCR 8. Moving the and pressing key we select the SCR slot
that we want to deactivate. Choosing from the SCR OFF list, all SCR slots will be deactivated,
as well as the SCR.
- SCR channel selection -
We can modify the frequencies of the SLOT using the "FREQUENCY SLOT"-key. Moving the
and pressing key we select the slot from which we wish to change the frequency. We
can choose the frequency by default, or another one. To select another frequency, we click on
Other, and with or key we can change the slot frequency. (The frequency is entered
in MHz).
