54
Measures Config.
By using the we can move through the list of DATALOGS . Once we have selected our
DATALOG of interest, by pressing the button we can access the results it has stored. The
data are displayed on a two-column table that shows on the left the sockets measured, and on
the right the results for each socket. By turning we will browse through the different
sockets of the DATALOG (left col.), and pressing we will change column (left to right and
right to left). Using the we will be able to move through the column we have selected.
Pressing the key we will return to the list of DATALOGS .
3.3.1.6.3.1.- Erasing DATALOGS
With this option we will eliminate the DATALOGS we have selected. For the purpose, on
we will find DATALOGS , selecting and deselecting them with button . The save marked will
be shown in yellow, and then we will press the option CONFIRM ending the erasure operation
by once again pressing the button the message " DATALOG ERASED " appearing on screen.
3.3.1.6.3.2.- Editing DATALOGS
From this option we can change the name of the desired DATALOG at any moment. For the
purpose, by using the we can select the DATALOG to be edited, confirming with the
button. The character selected will blink. Using or the cursors we can change
the selected character. To accept the change, we can press button . Using the cursors
we can move through the list of characters.
When a memory is erased or edited, one is also erasing or editing the Macromeasures
in which that memory has been included.
The fact of erasing or editing a
Macromeasures does not affect the DATALOGS that
have been generated with the erased or edited macromeasure.
