2.1.- METER COMPONENTS DESCRIPTION
On the front panel we have the following components:
- Front panel -
(1) Monitor
5.7" color TFT high definition screen
(2) Numerical keyboard and quick keys.
The numerical keyboard permits the introduction of the numerical values required
(frequency, channel, symbol rate values, ...).
Further on, the following symbol will be used to indicate the parameters whose
values may be introduced using the numerical keyboard.
Besides, some of the numerical keys are also quick keys for certain frequently-used
functions.
The paragraphs below provide a detailed explanation of all the functions, and those
possessing a quick key will be indicated by a symbol on the respective key.
1 3 13 14
10 8
12
4
6
5
9
2
7
11
