80 2 Setup
2.1 Set
u
p PC2-COMP Express frame grabber board
The IK 5000 supports the PC2-COMP Express, PCI Express frame
grabber board produced by TeledyneDalsa Inc. This frame grabber can
be used in place of the previous Bandit II frame grabber board. The
PC2-COMP Express can be installed in systems running Windows XP,
Vista and 7.
 This board must be obtained from HEIDENHAIN
 This board must be installed on a computer with PCI Express slot
 Bandit II and PC2-Comp Express cannot be installed at the same
time
PC2-COMP Express board
The PC2-COMP Express frame grabber board is
compatible with 32-bit operating systems only.
