32
Other Features
Saving/Recalling Settings (Preset Memory)
You can take the current settings, including video and audio settings and the state of the operation panel, and save them as a single set in
memory, for later recall and use when needed. The V-60HD is provided with eight preset memories.
About the last memory function
The V-60HD has a built-in Last Memory feature. Last Memory is a feature that saves the state of the unit that is in effect immediately before
power-down, and automatically restores the state at the next startup.
The Last Memory feature is enabled by default. When you want to call up a specified preset memory at startup, use the [MENU] button
0
“PRESET MEMORY” 0 ”START UP” to specify the memory number.
Saving to a preset memory
NOTE
When you have selected the [MENU] button 0 “PRESET
MEMORY” 0 “MEMORY PROTECT” and set this to “ON,” settings
cannot be saved to a preset memory.
1.
Press the [MODE] button to make it light up in blue.
Each press of the [MODE] button makes it toggle between lighting
up in blue and in green.
Lit blue
The AUX/MEMORY buttons function as memory selection buttons.
The currently selected AUX/MEMORY button lights up in blue.
2.
Press and hold (for 2 seconds or longer) the AUX/MEMORY
button for the number where you want to save the settings.
All AUX/MEMORY buttons briefly light up in blue, and the current
settings are saved.
MEMO
5 The state of the [OUTPUT FADE] button and [PHONES] knob are
not saved to any preset memory. The [OUTPUT FADE] button is
always dark at startup.
5 The state of the [MODE] button and the settings shown below
are saved as global settings for the unit. They are not saved to
preset memories.
Category Setting items saved in the unit
RS-232/GPI
All menu items
LAN CONTROL
SYSTEM
All setting items except “TEST PATTERN” and
“TEST TONE”
* “TEST PATTERN” and “TEST TONE” are always
set to “OFF” at startup.
5 You can use the [MENU] button 0 “PRESET MEMORY” 0
“SAVE” or “LOAD” to save or load a preset memory.
Recalling a preset memory
1.
Press the [MODE] button to make it light up in blue.
Each press of the [MODE] button makes it toggle between lighting
up in blue and in green.
Lit blue
The AUX/MEMORY buttons function as memory selection buttons.
The currently selected AUX/MEMORY button lights up in blue.
2.
Press the AUX/MEMORY button for the number whose
setting you want to recall.
The settings are recalled.
Deleting a preset memory
1.
Select the [MENU] button 0 “PRESET MEMORY” 0 “DELETE.”
2.
Use the [VALUE] knob to select the memory number
(1 through 8) that you want to delete, then press the
[VALUE] knob.
A confirmation message appears.
If you want to cancel the operation, press the [EXIT] button.
3.
Use the [VALUE] knob to select “YES,” then press the [VALUE]
knob.
The preset memory is deleted.
4.
Press the [MENU] button to quit the menu.
