Roland V-8HD HDMI Video Switcher - Manual (Page 53)

53
Menu List
Menu item Value
(Bold: default)
Explanation
KEY LEVEL 0– 64 –255 Adjusts the degree of extraction (transparency) for the key.
KEY GAIN 0– 255 Adjusts the degree of edge blur (semi-transmissive region) for the key.
MIX LEVEL 0– 255 Adjusts the key’s overall density (output level).
FILL TYPE BUS , MATTE
If this is “MATTE,” the superimposed logo or video is filled-in with the specified
color when using key compositing.
The fill-in color is specified by “MATTE COLOR” listed below.
MATTE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED , BLUE, BLACK
Specifies the color used when filling-in the superimposed logo or video.
* This is valid when “FILL TYPE” is set to “MATTE.”
EDGE TYPE
OFF , BORDER, DROP, SHADOW,
OUTLINE
Specifies the type of edge applied to the superimposed logo or video.
EDGE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Specifies the color of the edge applied to the superimposed logo or video.
EDGE WIDTH 0– 3 –14 Specifies the width of the edge applied to the superimposed logo or video.
9 PinP TYPE: LUMINANCE-BLACK KEY
Composites the video by applying a luminance key to the PinP to make its
black areas transparent.
Menu item Value
(Bold: default) Explanation
COPY SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Copies another PinP settings.
SWAP SETTINGS FROM
PinP 2 (or PinP 1)
EXEC Exchanges the settings of PinP 1 and PinP 2.
WINDOW Adjusts the inset screen.
POSITION H -50.0– -40.0 –50.0% Adjusts the inset screen’s display position horizontally.
POSITION V -50.0– -40.0 –50.0% Adjusts the inset screen’s display position vertically.
SIZE 10.0– 35.0 –100.0% Adjusts the size (zoom) of the inset screen.
CROPPING H 0.0– 100.0% Adjusts the horizontal size of the inset screen.
CROPPING V 0.0– 100.0% Adjusts the vertical size of the inset screen.
VIEW Adjusts the video that is shown in the inset screen.
POSITION H -50.0– 0.0 –50.0% Adjusts the horizontal position at which the inset screen is shown.
POSITION V -50.0– 0.0 –50.0% Adjusts the vertical position at which the inset screen is shown.
ZOOM 100.0 –1000.0% Adjusts the zoom of the inset screen.
KEY LEVEL 0– 64 –255 Adjusts the degree of extraction (transparency) for the key.
KEY GAIN 0– 255 Adjusts the degree of edge blur (semi-transmissive region) for the key.
MIX LEVEL 0– 255 Adjusts the key’s overall density (output level).
FILL TYPE BUS , MATTE
If this is “MATTE,” the superimposed logo or video is filled-in with the specified
color when using key compositing.
The fill-in color is specified by “MATTE COLOR” listed below.
MATTE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED , BLUE, BLACK
Specifies the color used when filling-in the superimposed logo or video.
* This is valid when “FILL TYPE” is set to “MATTE.”
EDGE TYPE
OFF , BORDER, DROP, SHADOW,
OUTLINE
Specifies the type of edge applied to the superimposed logo or video.
EDGE COLOR
WHITE, YELLOW, CYAN, GREEN,
MAGENTA, RED, BLUE, BLACK
Specifies the color of the edge applied to the superimposed logo or video.
EDGE WIDTH 0– 3 –14 Specifies the width of the edge applied to the superimposed logo or video.
