Main Specifications
Roland V-8HD: HD Video Switcher
9 Video
Video Processing 4:2:2 (Y/Pb/Pr), 8-bit
Input Connectors
INPUT 1–6
HDMI type A x 6
* HDCP supported
INPUT 7–8
HDMI type A x 2
* HDCP supported
* Multi-format supported
Output Connectors OUTPUT 1–3
HDMI type A x 3
* HDCP supported
Input Formats
INPUT 1–6
720/59.94p (*1) (*3)
720/50p (*1) (*4)
1080/59.94i, 1080/59.94p, 1080/60p, 1080/29.97p, 1080/30p (*2) (*3)
1080/50i, 1080/50p, 1080/25p (*2) (*4)
1080/23.98p, 1080/24p (*2)
* The input interlaced video signal is converted to progressive video signal by internal processing.
(*1) SYSTEM FORMAT = 720p
(*2) SYSTEM FORMAT = 1080i or 1080p
(*3) FRAME RATE = 59.94 Hz
(*4) FRAME RATE = 50 Hz
INPUT 7–8
480/59.94i, 480/59.94p, 720/59.94p, 1080/59.94i, 1080/59.94p, 1080/60p, 1080/29.97p, 1080/30p (*1)
576/50i, 576/50p, 720/50p, 1080/50i, 1080/50p, 1080/25p (*2)
1080/23.98p, 1080/24p
VGA (640×480/60Hz)
SVGA (800×600/60Hz) XGA (1024×768/60Hz)
WXGA (1280×800/60Hz) SXGA (1280×1024/60Hz) FWXGA (1366×768/60Hz)
SXGA + (1400×1050/60Hz) UXGA (1600×1200/60Hz) WUXGA (1920×1200/60Hz)
* The refresh rate is the maximum value of each resolution.
* Conforms to CEA-861-E,VESA DMT Version 1.0 Revision 11.
* 1920 x 1200/60 Hz: Reduced blanking
* The input interlaced video signal is converted to progressive video signal by internal processing.
(*1) FRAME RATE = 59.94 Hz
(*2) FRAME RATE = 50 Hz
Still Image
Bitmap File (.bmp) Maximum 1920 x 1080 pixels, 24-bit color, uncompressed.
PNG File (.png) Maximum 1920 x 1080 pixels, 24-bit color
* It can be stored up to 8 files in the internal memory.
* PNG α-channel not supported.
Output Formats
OUTPUT 1–2
720/59.94p (*1) (*4)
720/50p (*1) (*5)
1080/59.94i (*2) (*4)
1080/50i (*2) (*5)
1080/59.94p (*3) (*4)
1080/50p (*3) (*5)
(*1) SYSTEM FORMAT = 720p
(*2) SYSTEM FORMAT = 1080i
(*3) SYSTEM FORMAT = 1080p
(*4) FRAME RATE = 59.94 Hz
(*5) FRAME RATE = 50 Hz
OUTPUT 3
1080/59.94p (*1)
1080/50p (*2)
(*1) FRAME RATE = 59.94 Hz
(*2) FRAME RATE = 50 Hz
Video Effects
Transition CUT, MIX (DISSOLVE/FAM/NAM), WIPE (8 types)
Composition
PinP x 2 (SQUARE, CIRCLE, DIAMOND), SPLIT (2 types), Keyer x 2 (Luminance Key, Chroma Key),
DSK (Luminance Key, Chroma Key)
Others
Flip horizontal, Flip vertical, Still Image Capture, Still Image Playback, Output fade (Audio, Video: WHITE or BLACK),
Test pattern output
