60
Menu List
11: PRESET MEMORY
Menu item Value
(Bold: default)
Explanation
LOAD MEMORY 1 –8
Selects the preset memory to load.
Pressing the [VALUE] knob lets you load the preset memory.
SAVE MEMORY 1 –8
Selects a preset memory for saving settings.
Pressing the [VALUE] knob lets you save the settings to the preset memory.
* The state of the [PHONES] knob (headphone volume) is not saved in preset
memory.
* The following settings are common to the unit (one set for the entire unit),
and therefore are not saved in preset memory.
5 PRESET MEMORY menu
5 CTL/EXP menu
5 CAPTURE IMAGE menu
5 SYSTEM menu
INITIALIZE MEMORY 1 –8
Selects the preset memory to be initialized.
Press the [VALUE] knob to initialize the preset memory.
START UP
Specifies the settings loaded at startup.
LAST MEMORY
Restores the state that was in effect immediately before the power was turned
off (Last Memory function).
The current settings (Last Memory values) are saved every 4 seconds, and
when you exit a menu.
MEMORY 1–8 Recall the settings at the selected memory number.
MEMORY PROTECT OFF , ON
If this is “ON,” the preset memories are protected, and settings cannot be saved
to them.
PinP FADE TIME 0.0– 0.5 –1.0sec
Specifies the time over which the PinP 1 or PinP 2 inset screen disappears/
appears when a preset memory is recalled.
* If this is set to “0.0sec,” the PinP inset screen video might flicker briefly when a
preset memory is recalled.
LOAD PARAMETER Specifies the menu items that are applied when a preset memory is recalled.
VIDEO INPUT OFF , ON
Menu items for which this is “OFF” do not change when a preset memory is
recalled.
VIDEO OUTPUT OFF , ON
TRANSITION TIME OFF, ON
MIX/WIPE OFF, ON
SPLIT/VFX OFF, ON
PinP OFF, ON
DSK OFF, ON
AUDIO INPUT OFF , ON
AUDIO OUTPUT OFF , ON
AUDIO FOLLOW OFF , ON
12: STILL IMAGE
Menu item Value (Bold: default) Explanation
LOAD FROM USB
MEMORY
STILL 1 –8
Loads a still image from a USB flash drive and saves it in this unit.
Specifies the save-destination for the still image that is loaded from the USB
flash drive.
If a still image is already saved, an “ * ” is shown.
When you press the [VALUE] knob, a list of the still images on the USB flash
drive is shown.
Select the still image that you want to load, and press the [VALUE] knob to save
the still image in this unit.
DELETE STILL IMAGE STILL 1 –8
Here’s how to delete the still image that’s saved in the unit.
Select the still image that you want to delete.
Press the [VALUE] knob to delete the selected still image.
