Roland V-8HD HDMI Video Switcher - Manual (Page 74)

74
Appendix
6 Undefined (Controller Number 28)
This control the value of DSK GAIN.
Status 2nd Byte 3rd Byte
BnH 1CH vvH
vv = 00H–7FH (Converted to 0–255)
6 Undefined (Controller Number 29)
This control the value of DSK MIX LEVEL.
Status 2nd Byte 3rd Byte
BnH 1DH vvH
vv = 00H–7FH (Converted to 0–255)
6 Undefined (Controller Number 30)
This control the value of SPLIT/VFX A SW.
Status 2nd Byte 3rd Byte
BnH 1EH vvH
vv = 00H, 01H (OFF, ON)
6 Undefined (Controller Number 31)
This control the value of SPLIT/VFX A TYPE.
Status 2nd Byte 3rd Byte
BnH 1FH vvH
vv = 00H–11H (refer to p. 79)
6 Bank select (Controller Number 32)
This control the value of SPLIT/VFX B SW.
Status 2nd Byte 3rd Byte
BnH 20H vvH
vv = 00H, 01H (OFF, ON)
6 Modulation (Controller Number 33)
This control the value of SPLIT/VFX B TYPE.
Status 2nd Byte 3rd Byte
BnH 21H vvH
vv = 00H–11H (refer to p. 79)
6 Bless Controller (Controller Number 34)
This control the [OUTPUT FADE] knob position (counter-clockwise)
Status 2nd Byte 3rd Byte
BnH 22H vvH
vv = 00H–3FH
6 Undefined (Controller Number 35)
This control the [OUTPUT FADE] knob position (clockwise)
Status 2nd Byte 3rd Byte
BnH 23H vvH
vv = 00H–3FH
6 Foot Controller (Controller Number 36)
This control the value of AUDIO INPUT LEVEL (INPUT 1).
Status 2nd Byte 3rd Byte
BnH 24H vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Portamento Time (Controller Number 37)
This control the value of AUDIO INPUT LEVEL (INPUT 2).
Status 2nd Byte 3rd Byte
BnH 25H vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Data Entry (Controller Number 38)
This control the value of AUDIO INPUT LEVEL (INPUT 3).
Status 2nd Byte 3rd Byte
BnH 26H vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Channel volume (Controller Number 39)
This control the value of AUDIO INPUT LEVEL (INPUT 4).
Status 2nd Byte 3rd Byte
BnH 27H vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Balance (Controller Number 40)
This control the value of AUDIO INPUT LEVEL (INPUT 5).
Status 2nd Byte 3rd Byte
BnH 28H vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Undefined (Controller Number 41)
This control the value of AUDIO INPUT LEVEL (INPUT 6).
Status 2nd Byte 3rd Byte
BnH 29H vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Panpot (Controller Number 42)
This control the value of AUDIO INPUT LEVEL (INPUT 7).
Status 2nd Byte 3rd Byte
BnH 2AH vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Expression (Controller Number 43)
This control the value of AUDIO INPUT LEVEL (INPUT 8).
Status 2nd Byte 3rd Byte
BnH 2BH vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Effect Control 1 (Controller Number 44)
This control the value of AUDIO INPUT LEVEL (AUDIO IN).
Status 2nd Byte 3rd Byte
BnH 2CH vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Effect Control 2 (Controller Number 45)
This control the value of AUDIO OUTPUT LEVEL.
Status 2nd Byte 3rd Byte
BnH 2DH vvH
vv = 00H–7FH (refer to “Control Value–Input/Output Level Correspondence Table” (p. 75))
6 Undefined (Controller Number 52)
Presses or release the [CUT] button.
Status 2nd Byte 3rd Byte
BnH 34H vvH
vv = 00H, 01H (OFF, ON)
6 Undefined (Controller Number 53)
Presses release the [AUTO] button.
Status 2nd Byte 3rd Byte
BnH 35H vvH
vv = 00H, 01H (OFF, ON)
6 Undefined (Controller Number 54)
Switches the video as “ H CUT I .”
Status 2nd Byte 3rd Byte
BnH 36H vvH
vv = any (00H–7FH)
6 Undefined (Controller Number 55)
Switches the video as “ H AUTO TAKE I .”
Status 2nd Byte 3rd Byte
BnH 37H vvH
vv = any (00H–7FH)
