Menu List
15: CTL/EXP
CTL/EXP 1, 2
Menu item Value
(Bold: default)
Explanation
CTL/EXP TYPE
Specifies the device (footswitch, expression pedal) that is connected to the CTL/EXP jack.
OFF Disables the CTL/EXP jack.
CTL A & CTL B Choose this if a footswitch is connected.
EXP Choose this if an expression pedal is connected.
CTL A ASSIGN
CTL B ASSIGN
Specifies the functions that are assigned to CTL A and CTL B of the footswitch.
* This is valid when “CTL/EXP TYPE” is set to “CTL A & CTL B.”
N/A No function is assigned.
A/PGM CH SEL 1–8
Selects the video of the specified input channel as the video sent to the A/PGM
bus.
B/PST CH SEL 1–8
Selects the video of the specified input channel as the video sent to the B/PST
bus.
AUX CH SEL 1–8
Selects the video of the specified input channel as the video sent to the AUX
bus.
INPUT 1–8 ASSIGN Switches the source of the specified input channel.
STILL 1–8 OUTPUT Switches the output video to the specified still image.
PinP 1 SRC HDMI 1–8
Switches the video shown in the PinP 1 inset screen to the video of the
specified input channel.
PinP 1 SRC STILL 1–8 Switches the video shown in the PinP 1 inset screen to the specified still image.
PinP 2 SRC HDMI 1–8
Switches the video shown in the PinP 2 inset screen to the video of the
specified input channel.
PinP 2 SRC STILL 1–8 Switches the video shown in the PinP 2 inset screen to the specified still image.
DSK SOURCE HDMI 1–8
Switches the source image for DSK compositing to the video of the specified
input channel.
DSK SOURCE STILL 1–8 Switches the source image for DSK compositing to the specified still image.
CUT SW The same function as the [CUT] button.
AUTO SW The same function as the [AUTO] button.
TRANSITION SW The same function as the [TRANSITION] button.
MODE SW The same function as the [MODE] button.
SPLIT/VFX A SW The same function as the SPLIT/VFX [A] button.
SPLIT/VFX B SW The same function as the SPLIT/VFX [B] button.
PinP 1 PVW SW The same function as the PinP 1 [PVW] button.
PinP 1 ON SW The same function as the PinP 1 [ON] button.
PinP 2 PVW SW The same function as the PinP 2 [PVW] button.
PinP 2 ON SW The same function as the PinP 2 [ON] button.
DSK PVW SW The same function as the DSK [PVW] button.
DSK ON SW The same function as the DSK [ON] button.
USER 1 SW The same function as the USER [1] button.
USER 2 SW The same function as the USER [2] button.
H AUTO TAKE I Switches the video between A/PGM bus and B/PST bus.
H CUT I Switches the video between A/PGM bus and B/PST bus as a cut.
INPUT 1–8 AUDIO MUTE Turns the mute function on/off for the audio of the specified input channel.
AUDIO IN AUDIO MUTE Turns the mute function on/off for AUDIO IN audio.
AUDIO OUTPUT MUTE Turns the mute function on/off for AUDIO OUT audio.
AUDIO AUX MUTE Turns on/off the mute function for AUX-bus audio.
INPUT 1–8 AUDIO SOLO Turns the solo function on/off for the audio of the specified input channel.
OUTPUT FADE LEFT The same function as turning the [OUTPUT FADE] knob to the left.
OUTPUT FADE RIGHT The same function as turning the [OUTPUT FADE] knob to the right.
LOAD MEMORY 1–8 Recalls the specified preset memory.
