7 Audio Parameter Area
6 Audio Input
* “xxH” corresponds to the respective channels as indicated below.
xxH: 00H–08H (INPUT 1–8, AUDIO IN)
Address Parameter Name Sys.Ex.Value Meaning of Value
01H xxH 00H
01H
02H INPUT LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H– 00H 00H 64H -INFdB,
-80.0–0.0–10.0dB
01H xxH 03H INPUT MUTE 00H–01H OFF, ON
01H xxH 04H SOLO 00H–01H OFF, ON
01H xxH 05H EFFECT PRESET 00H–06H
DEFAULT, MEETING, INTERVIEW, AMBIENT MIC, WINDY FIELD,
DE-ESS/POPS SOFT, DE-ESS/POPS HARD
01H xxH 06H
07H
DELAY 00H 00H–27H 08H 0.0–500.0ms
01H xxH 08H HIGH PASS FILTER 75Hz 00H–01H OFF, ON
01H xxH 09H NOISE GATE SW 00H–01H OFF, ON
01H xxH 0AH
0BH
NOISE GATE THRESHOLD 79H 60H–00H 00H -80.0–0.0dB
01H xxH 0CH NOISE GATE RELEASE 00H–7FH 30–5000ms
01H xxH 0DH COMPRESSOR SW 00H–01H OFF, ON
01H xxH 0EH
0FH
COMPRESSOR THRESHOLD 7BH 28H–00H 00H -60.0–0.0dB
01H xxH 10H COMPRESSOR RATIO 00H–0DH
1.00:1, 1.12:1, 1.25:1, 1.40:1, 1.60:1, 1.80:1, 2.00:1, 2.50:1, 3.20:1,
4.00:1, 5.60:1, 8.00:1, 16.0:1, INF:1
01H xxH 11H COMPRESSOR ATTACK 00H–19H 0.2–100ms
01H xxH 12H COMPRESSOR RELEASE 00H–7FH 30–5000ms
01H xxH 13H COMPRESSOR AUTO GAIN 00H–01H OFF, ON
01H xxH 14H
15H
COMPRESSOR MAKEUP GAIN 7CH 70H–00H 00H–03H 10H -40.0–0.0–40.0dB
01H xxH 16H EQUALIZER SW 00H–01H OFF, ON
01H xxH 17H
18H
EQUALIZER Hi GAIN 7EH 6AH–00H 00H–01H 16H -15.0–0.0–15.0dB
01H xxH 19H EQUALIZER Hi FREQUENCY 44H–78H 1.00–20.0kHz
01H xxH 1AH
1BH
EQUALIZER Mid GAIN 7EH 6AH–00H 00H–01H 16H -15.0–0.0–15.0dB
01H xxH 1CH EQUALIZER Mid FREQUENCY 00H–78H 20Hz–20.0kHz
01H xxH 1DH EQUALIZER Mid Q 00H–05H 0.5–16.0
01H xxH 1EH
1FH
EQUALIZER Lo GAIN 7EH 6AH–00H 00H–01H 16H -15.0–0.0–15.0dB
01H xxH 20H EQUALIZER Lo FREQUENCY 00H–38H 20–500Hz
6 Audio Output Assign
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 10H 00H AUDIO OUT 00H–01H MASTER OUTPUT, AUX
01H 10H 01H PHONES OUT 00H–01H MASTER OUTPUT, AUX
6 Audio Master Output
Address Parameter Name Sys.Ex.Value Meaning of Value
01H 11H 00H
01H
02H
OUTPUT LEVEL
7EH 00H 00H,
7FH 79H 60H–00H 00H 00H–00H 00H 64H -INFdB,
-80.0–0.0–10.0dB
01H 11H 03H OUTPUT MUTE 00H–01H OFF, ON
01H 11H 04H LIMITER SW 00H–01H OFF, ON
01H 11H 05H
06H
LIMITER THRESHOLD 7CH 70H–00H 00H -40.0–0.0dB
01H 11H 07H EQUALIZER SW 00H–01H OFF, ON
01H 11H 08H
09H
EQUALIZER Hi GAIN 7EH 6AH–00H 00H–01H 16H -15.0–0.0–15.0dB
01H 11H 0AH EQUALIZER Hi FREQUENCY 44H–78H 1.00–20.0kHz
01H 11H 0BH
0CH
EQUALIZER Mid GAIN 7EH 6AH–00H 00H–01H 16H -15.0–0.0–15.0dB
01H 11H 0DH EQUALIZER Mid FREQUENCY 00H–78H 20Hz–20.0kHz
01H 11H 0EH EQUALIZER Mid Q 00H–05H 0.5–16.0
01H 11H 0FH
10H
EQUALIZER Lo GAIN 7EH 6AH–00H 00H–01H 16H -15.0–0.0–15.0dB
