Airpeak S1
ARS-S1
Loading battery packs in the aircraft
Load the two battery packs in battery slots 1 and 2 at the rear of the aircraft.
Hint
Battery levels can be checked by pressing the battery level button on each battery pack. Before flights, be sure to confirm that the
battery levels are enough for the flights you have planned.
To unload a battery pack, press the BATTERY RELEASE lever and remove it.
Load the battery packs in the aircraft.
Insert firmly until the battery packs click and lock into place.
1
Confirm that the battery packs are loaded correctly.
Battery packs are not loaded correctly if a yellow line (
) is visible and the BATTERY RELEASE lever (
) has not
returned to the original position. Firmly insert battery packs all the way in.
Loaded correctly
Loaded incorrectly
2
