CDM-550T Satellite Modem
Revision 3
Front Panel Operation
MN/CDM550T.IOM
6.2.5.6
(INFO) REMCONT (Remote Control information)
This screen shows if the unit is in LOCAL or REMOTE mode, and gives details of the electrical
interface type selected, the unit’s address, and the baud rate selected. Pressing ENTER takes the
user back to the previous menu.
REM-CONTROL:ON RS485-4W
ADDRESS: 0001 19200 BAUD
6.2.5.7
(INFO) MASK (Alarm mask information)
This shows, in the same format as the CONFIG: MASK sub menu, which alarms are currently
masked. If an alarm is not masked, a blank is displayed in the relevant screen position.
ALARMS MASKED:
RX-AIS TX-AIS
6.2.5.8
(INFO) MISC (Miscellaneous information)
This screen shows the following:
MISC: IF-LOOP 50 OHMS
1:1 LINK IDLE ONLINE
Test mode
IF impedance
1:1 link status - if the CRS-100 1:1 module is being used, this shows the status of
the serial link between the two units.
Redundancy status - either online or standby (1:1 or 1:N)
Pressing ENTER takes the user back to the previous menu.
6–29
