GAI-TRONICS
VoIP Telephone Configuration Guide Page 46 of 88
ON Sets the LED permanently on.
OFF Sets the LED permanently off.
PULSE +
Sets the LED to illuminate once only for the period defined by the
TIMER field, on receipt of a Recall signal from a remote phone.
MUTE + Sets the LED to indicate if the audio input is muted.
RING +
Sets the LED to flash when an incoming call is ringing. The flashing
on /off periods are set by the CADENCE field.
CALL +
Sets the LED to flash when an outgoing call is active. The flashing on
/off periods are set by the CADENCE field.
CONNECT + Sets the LED on when a call is connected.
HOOK +
Sets the LED on when the telephone is off hook, and off when it is
back on hook.
INUSE +
Sets the LED on when an incoming call arrives or when the user goes
off hook for an outgoing call, and off when the call ends.
RINGCADENCE +
Causes the LED to flash in time with the incoming ring signal cadence.
This cadence is set by the parameters for Tone 7 (TONES page,
section 5.15).
RINGOUT +
Sets the LED to flash when an outgoing call is ringing (but not yet
connected). The flashing on /off periods are set by the CADENCE
field.
PAGE +
Sets the LED to flash when a call is present that has been signalled as
a PAGEMODE call (see UNIT page, section 5.5). The flashing on /off
periods are set by the CADENCE field.
REGISTERED +
Sets the LED to flash when the phone is registered with at least one
SIP server. Can be used as a “phone available” indicator. The
flashing on /off periods are set by the CADENCE field.
EMERGENCY +
Sets the LED to flash whenever there is an outgoing call present that
has been initiated by an EMERGENCY button. The flashing on /off
periods are set by the CADENCE field.
The ON and OFF keywords must be used on their own. The other keywords (indicated by a +
symbol in the table above), can be combined and entered in any order, separated by a plus
(+) character. For example to set an LED to flash when an incoming call is ringing, and
illuminate steadily when the call is connected enter RING+CONNECT.
TIMER: Sets the timer value for the PULSE command in seconds. Default value is 3. The
minimum is 0 & the maximum is 3600.
CADENCE: Sets the cadence for those keyword commands that require it. The cadence is
entered as two numbers separated by a colon (:) character, representing the on and off times
in tenths of a second. For example to set a cadence of 1 second on, half a second off, enter
10:5.
