GAI-TRONICS
VoIP Telephone Configuration Guide
Page 61 of 88
Section Item
Identifier
Value(s) Comments
OFF
[LED1 | LED2 | LED3]]
GENERAT
E
(Items
marked "+"
can be
combined in
any order
separated
by a "+"
symbol
OFF
This command sets the function of LED 1 or 2 to be
off. (Default State)
PULSE+
This command will cause the LED to illuminate for the
period defined by the TIMER command, when an
activation message is received from a remote unit
MUTE+
This command sets the function of LED 1 or 2 to
indicate if the audio input is muted.
RING+
This command sets the function of LED 1 or 2 to be
enabled when an incoming call is present and ringing,
and the on /off period will be as defined by the SET
CADENCE commands
CALL+
This command sets the function of LED 1 or 2 to be
flashing when an outgoing call is present with an on
/off period which is as defined by the LOGIC SET
CADENCE commands
CONNECT+
This command set the function of the LED output 1
OR 2 to be enabled when a call is connected. If the
ANI feature is enabled, the LED output is enabled
only when the call is connected and DTMF # has
been received.
HOOK+
This command sets the function of the LED output 1
OR 2 to show the status of the hook switch or
ON/OFF/TOGGLE button states. When the unit is
OFF_HOOK or ON the LED will be enabled. When
the unit is ON_HOOK or OFF the LED will be
disabled
INUSE+
This command sets the function of the LED output 1
or 2 to be enabled when an incoming call arrives or
when the user goes off hook for an outgoing call, and
disabled when the call ends.
RINGCADEN
CE+
Causes the LED to flash in time with the incoming
ring signal cadence. This cadence is set by the
parameters for Tone 7 (TONES page).
PAGE +
Sets the LED to flash when a call is present that has
been signalled as a PAGEMODE call (see UNIT
page, section 5.5) The flashing on /off periods are set
by the CADENCE field.
REGISTERED
+
Sets the LED to flash when the phone is registered
with at least one SIP server. Can be used as a
“phone available” indicator. The flashing on /off
periods are set by the CADENCE field.
EMERGENCY
+
Sets the LED to flash whenever there is an outgoing
call present that has been initiated by an
EMERGENCY button. The flashing on /off periods
are set by the CADENCE field.
ON
This command sets the function of the LED 1 or 2
outputs to be enabled when an incoming call arrives
or when the user goes off hook for an outgoing call,
and disabled when the call ends.
[LED1 | LED2 | LED3]]
TIMER
XX
This command sets the timer value for the LED, used
in the PULSE command where XX is the time in
seconds. Default value is 3
[LED1 | LED2 | LED3]]
CADENCE
ON:OFF
This command sets the cadence for an LED. To be
on for ON/10 seconds where ON is in tenths of
seconds, and then OFF for OFF/10 seconds. The
default value for ON is 10, and OFF is 0 implying the
contact does not “flash”.
LOCAL
SPEED
9600
Sets the Port speed to be 9.6 Kbps
19200
Sets the Port speed to be 19.2 Kbps
38400
Sets the Port speed to be 38.4 Kbps
57600
Sets the Port speed to be 9.6 Kbps
115200
Sets the Port speed to be 115.2 Kbps (Default)
LOGIC
[ INPUT1 | INPUT2 |
INPUT 3 |
INPUT 4 ]
DETECT ON
This command enables the generation of messages
for the assertion of an auxiliary input. Default setting
is NONE for all inputs.
DETECT OFF
This command enables the generation of messages
for the de-assertion of an auxiliary input. Default
setting is NONE for all inputs.
DETECT NONE
This command disables the generation of messages
for the auxiliary input.
