GAI-TRONICS
VoIP Telephone Configuration Guide Page 64 of 88
Section Item Identifier Value(s) Comments
REGISTRAR
xxx.xxx.xxx.xxx
or FQDN
This command sets the address of the Registrar to be
xxx.xxx.xxx.xxx or the FQDN specified. The registrar
address and the proxy may or may not be the same
address, but the address for registration must be set
here.
REGISTRARPO
RT
XXXX
The port to send the register to.
USERNAME “username”
This command sets the username for the
authorisation realm to be username ( Default value is
blank)
PASSWORD “password”
This command sets the password for the
authorisation realm to be password ( Default value is
blank)
ENDPOINT [ENABLED | DISABLED] Sets whether this set of proxy parameters is active.
SMTP
SERVER1
xxx.xxx.xxx.xxx
or
FQDN
Sets the IP address of the primary SMTP server to be
xxx.xxx.xxx.xxx or uses the FQDN to resolve the IP
address through DNS. Email will be sent on assertion
of an alarm condition via the primary server if
configured.
SERVER2
xxx.xxx.xxx.xxx
or
FQDN
Sets the IP address of the secondary SMTP server to
be xxx.xxx.xxx.xxx or uses the FQDN to resolve the
IP address through DNS. Email will be sent on
assertion of an alarm condition via the secondary
server if configured.
TOADDRESS [email protected] Sets the To: Address
CCADDRESS [email protected] Sets the CC: Address
FROMADDRESS [email protected] Sets the FROM: Address
SUBJECT “SubjectText”
Set the contents of the subject field to be
“SubjectText”. The Subject Text field can be up to 50
characters in length, and can contain any printable
character except double quotes.
SMTP [ON|OFF]
This setting enables or disables the use of SMTP
within the unit.
TONES
[TONE1 –TONE10]
FREQ 1-13 These commands set the various call tones produced
by the telephone.
See Tone Settings web page section (5.15) for
detailed explanation.
For example to set a standard UK and US ring tones
the commands would be:
ON1
0-600 (*25ms)
OFF1
ON2 UK US
OFF2
TONE3=FREQ 5
TONE3=ON1 0
TONE3=OFF1 0
TONE3=ON2 16
TONE3=OFF2 8
TONE3=ON3 16
TONE3=OFF3 80 TONE3=FREQ 3
TONE3=ON1 0
TONE3=OFF1 0
TONE3=ON2 80
TONE3=OFF2 160
TONE3=ON3 0
TONE3=OFF3 0
ON3
OFF3
UNIT
HOSTNAME xxxxxxxx
Sets the unit host name for this unit to be
XXXXXXXXXXXX where X is any alphanumeric
character. Maximum of 15 characters. Default Value
is "UNNAMED”.
UPDATE SERVER
xxx.xxx.xxx.xx
x
or
FQDN
Sets the IP address of the host running the TFTP
server to be xxx.xxx.xxx.xxx or resolves the FQDN
using DNS to access the host containing the update
file(s).
UPDATE FILE Filename
The name of the file on the TFTP server. This name
may contain the macro symbols %m, %h and %i.
These symbols are expanded to the MAC address,
host name and IP address respectively.
UPDATE INTERVAL X
This command forces the unit to attempt a
configuration file download every X hours where X
can be an integer value between 0 and 1000. A value
of 0 disables the periodic update request. The default
value is 1. Any non-zero value will cause the unit to
attempt a configuration file download at boot time.
HELPSERVER
xx.xxx.xxx.xxx
or
FQDN
Sets the address for the Web Support Page link on
the Home page.
LAN SPEED AUTO|10|100 Ethernet speed
