ADVANCE System
SmartView Software User Manual
Version 1.3
Confidentiality Notice
This manual is provided solely as an operational, installation, and maintenance guide and contains sensitive
business and technical information that is confidential and proprietary to GAI-Tronics. GAI-Tronics
retains all intellectual property, other rights in or to the information contained herein, and such information
may only be used in connection with the operation of your GAI-Tronics product or system. This manual
may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party.
SmartView Software Overview
The GAI-Tronics ADVANCE System SmartView Software suite consists of two different software
applications.
ADVANCE Server
The ADVANCE Server program runs on a PC connected to the ADVANCE Ethernet network. The
system configuration database file (.hot file) created by the ADVANCE Console program, is loaded into
the server. The server then collects status information from each of the ADVANCE cabinets on the
network. Status information includes faults, pages, alarms, input activations and output activations. The
server sends all information to one or more SmartView Portals. Refer to the “ADVANCE Server
Software” section of this manual on page 9 for detailed information.
N OTE : There can only be one instance of the ADVANCE Server running in a system.
SmartView Portal
The SmartView Portal program is used by the system operators to monitor system activity and receive
real-time fault reporting of ADVANCE system components. The program features a graphical
representation of the system along with selection buttons for navigating through various screens to view
system status. Multiple PCs can run SmartView Portal, providing more than one monitoring location.
Refer to the “SmartView Portal Software” section of this manual on page 18 for detailed operation.
