25
3. The remainder of the procedure for setting wireless high-speed sync, is the same as for normal high-speed sync.
◆ It is not necessary to make any additional settings on the Slave units.
Wireless Flash Exposure Compensation
1. Please set master flash unit to the Wireless Flash Mode.
2. Press the SEL button to make
mark blink.
3. Press the + or - button to set the flash exposure compensation amount.
4. Press the SEL button several times to make exposure compensation indicator appear.
◆ It is not necessary to make any additional setting on the Slave units.
◆ You can also set the flash exposure compensation individually for each slave unit. (If using more than
one slave, you will need to apply steps 2-4 to each slave unit.)
Wireless FE Lock
1. First please set the flashgun to Wireless Flash mode.
2. Focus on the subject and press the FEL button on the camera.
3. The procedure for setting wireless EF lock is the same as for normal FE lock.
◆ It is not necessary to make any change to the settings on the Slave units.
Wireless Flash Exposure Bracketing (FB)
1. First set the flash to the Wireless Flash Mode.
2. On the Master Unit, press the SEL button several times to make the
mark blink.
3. Press the + or - button and set the flash exposure compensation amount.
4. Press the SEL button several times to make the indicator stop blinking.
5. The remainder of procedure for setting wireless FB is the same as for normal FB.
◆ It is not necessary to change any settings on the Slave units.
CHANGING THE WIRELESS MODE
Please set the flash as follows.
1. Press the MODE button to select the ETTL / mark.
2. Press and hold the SEL button more than 2 seconds to make the mode indicator blink.
3. Press the MODE button and select the ETTL, M, or MULTI mode.
4. Press the SEL button to make the mode of indicator stop blinking.
WIRELESS MANUAL FLASH
You can manually set the slave unit’s flash output, with the master unit. The flash output among the slave
units can be uniform or varied. To determine the proper flash exposure, use a hand-held flash meter.
Wireless Manual Flash With Uniform Flash Output
Please set the Master flash unit as described below.
1. Please follow the procedure of Changing the Wireless Mode and set to the M／
mark.
2. Press the SEL button several times to make the flash output amount indicator blink.
3. Press the + button or – button to set the flash output amount.
4. Press the SEL button several times until the display stops blinking.
◆
If the master flash unit ON function is set, the master unit will also fire, at the same flash output.
Wireless Manual Flash With Varied Flash Output
You can set a different flash output for each slave unit(s) (the following explains the procedure for using
three slave flash units). Set the slave units to normal Wireless Flash mode.
Please set the master flash unit as follows.
1. Please follow the procedure for Changing the Wireless Mode and set to the M／ mark.
2. Press the SEL button several times to make the mark blink.
3. Press the
+ or - button to select indicator. (blinking)
4. Press the SEL button, making the flash output display and blink.
5. Press the
+ or - button to set the flash output amount for ID 1.
6. Press the SEL button make the flash output display and blink.
7. Press the
+ or - button to set the flash output amount for ID 2.
