26
8. Press the SEL button make the flash output display and blink.
9. Press the
+ or - button to set the flash output amount for ID 3.
10. Press the SEL button to make the indicator stop blinking.
◆ If there are only two slave units, please select the indicator at step 3 ( step 9 and step 10 should be
omitted).
WIRELESS MULTI FLASH
Set the master flash unit as follows.
1. Follow the procedure for Changing the Wireless Mode, and set to the MULTI／ mark.
2. Press the SEL button to make the firing frequency display blink.
3. Press the
+ or - button to set the firing frequency.
4. Press the SEL button to make the flash output amount display blink.
5. Press the
+ or - button to set the flash output amount.
6. Press the SEL button to make the flash count display blink.
7. Press the
+ or - button to set the flash count.
8. Press the SEL button to make the display stop blinking.
◆ The firing frequency and flash count will be the same for all slave units.
SLAVE FLASH
◆ When selecting this mode with the MODE button, make sure that the flash indicator mode (ETTL, M,
MULTI) is not displayed.
NORMAL SLAVE FLASH
Even if the EF-610 DG SUPER is not attached to the camera body, you can fire the flash by using another
flash unit.
◆ Built-in flash (E-TTL, E-TTL II) cannot be used.
◆ Please set your Master Flash unit to TTL autoflash (E-TTL, E-TTL II autoflash cannot be used) or Manual
flash mode.
1. Attach the flash unit to the camera’s hot shoe.
2. Set the camera’s exposure mode to the desired mode. If you use A or M mode, also set the desired aperture value.
3. Turn on the flash unit and press the shutter button half way.
◆ Now, the aperture value and film speed are automatically
transmitted to the flash unit.
4. Remove the flash unit from the camera.
5. Press the MODE button and select the
/ (Slave) mode.
6. Press the SEL button several times to make the flash output value
indicator blink.
7. Press the + or – button to set the flash output amount.
◆ Determine the appropriate flash output by setting the distance indicator on the LCD panel to coincide as
closely as possible with the actual distance from the slave flash to the subject. If the actual distance is
out of range, you will need to change the aperture value or film speed.
a. To change the aperture value: When the flash unit is set to the Slave mode, press the SEL button
until the aperture value blinks, then press the + or – button to set the desired aperture value. Then
press the SEL button to stop the display blinking.
b. To change the film speed: Press MODE to select the ISO, then press the SEL button to make the
indicator for the aperture value blink. Press the + or – button and set the desired film speed, then
press the SEL button once again. You will need to press the MODE button several times to return to
the slave mode.
8. Press the SEL button several times to make the display stop blinking.
9. Place the slave unit in the desired location. Do not place the slave unit within the picture area.
10. After confirming that all flash units are fully charged, press the shutter button to take the picture.
◆ When the EF-610 DG SUPER is fully charged, the AF Auxiliary Light will blink.
◆ The flash will not fire if the EF-610 DG SUPER is attached to the camera body while it is in the Slave
Mode setting.
