Teac DR-07MKII - Manual (Page 34)

34
TASCAM DR-07MKII
2–Names and Functions of Parts
Playback Control screen
The Playback Control screen is displayed if the
PB CONT button is pressed during playback or
when playback is stopped.
Recording cannot be performed while this
screen is displayed. Press the  or ¯
button to skip to the I/O point or the beginning/
end, instead of the previous or next file.
1 Loop playback status
The icon is displayed when loop
playback is enabled.
2 Playback speed
Playback speed as compared with the normal
speed is shown.
VSA
shown on the left to indicate that the
VSA (variable speed audition: enables the
tempo to be changed without changing the
pitch) function is enabled.
3 Playback position display
The current playback position is shown by a bar. As
playback progresses, the bar extends to the right.
4 Loop playback IN (starting) and OUT
(ending) points
The set starting and ending points of the
loop are shown.
The icon appears at the playback position
on the bar when the starting point is set.
The icon appears at the playback position
on the bar when the ending point is set.
5
Available buttons
The buttons available in the Playback Control
screen are as follows.
MARK
: Creates or deletes an IN or OUT point.
MENU
: Switch over between ON and OFF
status of the loop playback function.
NOTE
Unlike the other screens, the QUICK button in this screen
works to display the quick menu containing only the LEVEL
ALIGN function, and no other functions will be available.
