45
3. Set the “Mode”, “Frame size”, “Viewer window area”, “Maximum frame rate” and “Video quality”
of the Video Profile as necessary.
4. Set the details of the audio functions.
5. Select 50 Hz or 60Hz of the Power Line.
6. Click on the Submit button to submit the new setting.
Description of function keys:
Profile Number
Select the Profile Number from 1-3 and the default video profile
number is 2.
Aspect ratio
The aspect ratio of an image is the ratio of the width of the image to its
height. Select 4:3 or 16:9 of the ratio that best suits your needs.
Mode:
Choose the video format from “H.264”,“JPEG” or “MPEG4”. It can be
either JPEG or MPEG4. In JPEG mode, the video frames are
independent. However, MPEG4 consumes much less network
bandwidth than JPEG.
Frame size:
This option allows the user to choose the video resolution of the
camera:
1.3 Mega-pixel:
4:3 - “2048x1536”, “1600x1200”, “1024x768“, “800x600”, “640x480”,
“480x360”, “320x240” and “176x144”.
16:9 - “1920x1080”, “1280x720”, “800x450”, “640x360”, “480x270”,
“320x176” and “176x144”.
2.0 Mega-pixel:
4:3 - “1440x1080”, “1280x960”, “1024x768“, “800x600”, “640x480”,
“480x360”, “320x240” and “160x120”.
16:9 - “1920x1080”, “1280x720”, “800x450”, “640x360”, “480x270”,
“320x180” and “176x120”.
3.0 Mega-pixel:
4:3 - “2048x1536”, “1600x1200”, “1024x768“, “800x600”, “640x480”,
“480x360”, “320x240” and “176x144”.
16:9 - “1920x1080”, “1280x720”, “800x450”, “640x360”, “480x270”,
“320x176” and “176x144”.
Viewer window area:
This option allows the user to choose the video resolution of the live
view area:
1.3 Mega-pixel:
4:3 - “2048x1536”, “1600x1200”, “1024x768“, “800x600”, “640x480”,
“480x360”, “320x240” and “176x144”.
16:9 - “1920x1080”, “1280x720”, “800x450”, “640x360”, “480x270”,
“320x176” and “176x144”.
2.0 Mega-pixel:
4:3 - “1440x1080”, “1280x960”, “1024x768“, “800x600”, “640x480”,
“480x360”, “320x240” and “160x120”.
16:9 - “1920x1080”, “1280x720”, “800x450”, “640x360”, “480x270”,
“320x180” and “176x120”.
