Eneo GXC-1720M User Manual
Page 52
52
Description of function keys:
HTTP Port
HTTP ports allow you to connect to the camera via a standard web
browser. This port can be set to a number other than the default HTTP port
80. A corresponding port must be opened on the router. For example, if the
port is changed to 8080, users must type in the web browser
'http://192.168.0.100:8080' instead of 'http://192.168.0.100'.
HTTPS Port
HTTPS Port in a camera connects it with a PC via a secure web browser.
RTSP Port
The port number that you use for RTSP streaming to mobile devices, such
as mobile phones or PDAs. You may specify the address of a particular
stream. For instance, live1.sdp can be accessed at
rtsp://x.x.x.x/video1.sdp where the x.x.x.x represents the IP address of
your camera.
NOTE: Using a RSTP player to view the video streams
To view the MPEG4 streaming media by using RTSP players, you can use the players that
support RTSP streaming, such as Quick Time Player, Real Player, and so on.
(1)
Launch the RTSP player.
(2)
Choose “File”, and an “Open URL” dialog box will pop up.
(3)
Enter an Internet URL to open. The address format is rtsp://<ip address>:<rtsp
port>/<RTSP streaming access name for stream1, stream2 or stream3>
(4)
The live video will be displayed in your player.
