Main Window
Profile LVS Event Management System Instruction Manual
4-5
Main Window
Figure 4–3 shows the Main Window as it appears after the Start button has been
pressed. Many system functions, such as configuration and disk cleanup, are
accessed from the Main Window.
ACG.. You cannot change the system configurations for Resource Assign,
Resource Setup, or Routing after pressing Start. However, you can change the
other configuration items without restarting the LVS software. Refer to System
Configuration and Startup, beginning on page 3–1 for details.
The Launcher also opens once system configuration has been completed. All the
windows can be opend and closed from the Launcher, except for the Main
window and the Preview window. Refer to Launcher on page 4–11 for more
information.
Figure 4-3: Main Window
Description
TC (TimeCode) 
The system timecode. The times for all the scenes are
referenced to this timecode.
This time code is free–running, generated internally by the Profile system. The
time code can be initialized to an external longitudinal time code (LTC), or
manually preset, as previously described on page 2–12.
Displayed Information
