Grass Valley LVS 100 v.3.15 - Manual (Page 93)

System Configuration and Startup
Profile LVS Event Management System Instruction Manual
3-3
Configuration Window
Select Setup from the menu bar of the LVS Event Management System Window.
The Configuration Window appears. In the Configuration Window (Figure 3–2),
you can confirm and modify system settings.
Figure 3-2: Configuration Window and Resource Assign Tab
The Configuration Window consists of three buttons and the following five tabs:
H Resource Assign
H Resource Setup
H Video Routing
H Timecode Routing
H Other
Click the name at the top part of the window to open the desired tab. Set the
system configuration by opening these tabs one by one. The Filing panel in the
Other tab lets you save your configuration settings in a file, or load previously
saved settings from a file.
