Profile LVS Event Management System Instruction Manual

C-1

Appendix C: Specifications

The specifications of this system are described below.

Hardware

Table C-1: Profile ConfigurationĂ

Item

Description

Configurations supported by the system

Any type of PDR200.
The LVSsupports the expansion disk unit PDX 208 .

(INIT1 partition including the Profile disk and Expansion unit only is supported.)
The LVSsupports the Mix/Effects board as an option.

VRAM

2 M bytes are required on the Profile.

(Images on the monitor deteriorates with 1 M byte VRAM)

SVGA Monitor

65,536 (64 k) color SVGA monitor is required to ensure accurate display of clip

icons.

Number of input channels

Up to 3 analog composites

Up to 4 digital components
Combinations of these are determined by the number of slots and power capacity.

Number of output channels

Up to 4 analog composites

Up to 4 digital components
Combinations of these are determined by the number of slots and power capacity.

Recording duration

3 hours with standard unit, and can be extended up to 6 hours (when the

compression target is 1/7) without using an external disk unit.

By connecting an expansion chassis, a much longer recording duration is possible.

Contact your Tektronix representative for details.

Number of controllers connected

Up to 2 controllers with the Live Controller, 1 controller with model DTRĆ3000, and

up to 2 controllers when using both controllers.

Limitations

Minimum delay in delayed transmission

5 seconds

Enter/Cue Up shortest cue point

5 seconds

Range of compression target

1/3.5 to 1/10

(For NTSC 100 K bytes/field on Configuration Window corresponds to 1/3.5)

Others

Approx. 1 second is required to switch between PLAY and SEARCH by using

SHIFT + SEARCH. When jog operation is executed by multiple controllers at the

same time, the process speed may be reduced.
