Timeline Window

Profile LVS Event Management System Instruction Manual

4-75

Insert Button

Permanently inserts the event which was temporarily placed on

the timeline in Insert mode. The inserted event replaces existing material on the
timeline at that point.

CUE

Cues up the currently selected event’s IN point, minus the current

pre–roll time. If no events are selected, cues the first event in the timeline, minus
the pre–roll time.

You can also cue up by performing a search operation in event mode on the Live
Controller.

PLAY

Starts playing back from the current playback point. This is the same as

pressing the PLAY button on the Live Controller.

In the Timeline window, playback is performed only in CONT (Continuous)
mode.

STOP

Stops playing back. This is the same as pressing the STOP button on

the Live Controller.

By using the Live Controller, you can also perform the following operations:

JOG

SHUTTLE

VAR

TOP

Allows the LVS to cue up at the top point of a timeline list,

SHIFT + TOP

Allows the LVS to cue up at the last point of a timeline list.

Prev. Button

Extends the selected area on a track to the IN point of the

previous event. This button can be used repeatedly. For example, if you select a
single event and then click this button three times, the three events to the left of
the initial event (earlier) will be added to the selected area, for a total of four
events.

Next Button

Extends the selected area on a track to the OUT point of the next

event. This button can be used repeatedly. For example, if you select a single
event and then click this button three times, the three events to the right of the
initial event (later) will be added to the selected area, for a total of four events.

Divide Button

Divides an event into two at the current playback point.

If you only want to use the middle part of a long event, divide the event twice to
create an event containing only the required material, then put the unwanted
portions in the Recycle Box.

To divide an event in two, move the playback point to the desired division point,
then click on the DIV. button. You can move the playback point by clicking the
timeline bar, or by using the playback controls.

Playback Control Buttons

Audio Split Buttons
