Removal and Installation Procedures

9-16

Profile LVS Event Management System Instruction Manual

PowerSupply Shield

PowerSupply

SpacerPosts M3, 12.5MM 3

Screws M3 6MM, PNH 3

Screw M3 6MM,

PNH

CP2

CP51

Ground Cable

coming from the LCD module

Figure 9-7: Power Supply Removal
