Diagnostics
9-30
Profile LVS Event Management System Instruction Manual
Press 4 when the Main menu is displayed on the LCDs. Then following LCD
TEST menu will appear.
[LCD TEST] 0: Return to menu
PLAY: Starting LCD test.
STOP: Stop testing.
Press PLAY to start the LCD test. When the test starts, a character set appears in
each line on the upper and lower LCDs, and moves right to left. Confirm that the
characters are being displayed properly.
!""#$%&'()*+,-./0123456789:;<=>?@ABCDEFG
!""#$%&'()*+,-./0123456789:;<=>?@ABCDEFG
!""#$%&'()*+,-./0123456789:;<=>?@ABCDEFG
!""#$%&'()*+,-./0123456789:;<=>?@ABCDEFG
Press STOP to stop the test.
Press 0 to return to the Main menu.
Press 5 when the Main menu is displayed on the LCDs. The following messages
will appear.
[SOLENOID/ADC/ENCODER/CLUTCH TEST]
0: Return to menu
ADC: 116 SLNID: OFF
ENC: <-000 000-> ORG: 0 CLTCH: OFF
ADC indicates a position of the lever. When you move the lever forward to
MAX FWD position, the value approaches 0. When you move it backward to
MAX REV, the value approaches 255. This value varies between 0 and 255
depending on the lever’s position.
SLNID indicates OFF while the lever handle button is released, and turns ON
when you press it.
LCD Test
Lever and Knob Operation
Test
