46
Configuration
Multi-Destination Configuration
MD Destination Options
On the right side of the multi-destination entry editor, each MD destination has two check-
boxes. One is in the ‘User Definable’ column and the other is in the ‘User Selectable’ column.
User-Definable
When the MD destination is “user definable,” the operator may choose a different destination
using the panel buttons. “User definable” is the default for all MD destinations. Uncheck the
‘User Definable’ box if you want to prevent the operator from changing this MD destination.
User-Selectable
When the MD destination is “user selectable,” the operator may select it and assign a different
source to it using the panel buttons. That is also the default for all MD destinations. Uncheck the
‘User Selectable’ box if you want to prevent the operator from taking a source to this
destination.
