83
NV9648
User’s Guide
Environmental Specifications
Table provides environmental specifications for the NV9648.
Defaults
Initial Panel State
Destination: the configured default.
Buttons: low-tally is 40% brightness by default and stays at its most recent setting.
Configuration Page
The initial NV9648 configuration has no buttons defined. The default panel options are:
Behavioral model: ‘Panel Client’ mode.
Release mode: Normal.
Display 1 device: None.
Display 2 device: None.
Display 3 device: None.
Display 3 device: None.
Master panel: None
Panel options for the other behavioral models are not in effect.
The tally inputs and outputs are all initially undefined.
DHCP
The panel is set up to respond to DHCP from the factory. It is possible to assign the panel a fixed
IP address using the Panel IP Configuration Utility.
Drawings
The following drawings identify panel features and provide overall and critical dimensions.
NV9648 Environmental Specifications
Specification Detail
Operating temperature 0–40°C, ambient.
Relative humidity 0 to 90%, non-condensing.
Cooling No fan required.
