69
NV9648
User’s Guide
Software Versions
Press the ‘Software Versions’ button to view the software and firmware versions:
The 3 buttons at the left tell you the current versions of the software in the NV9648. Generally,
this is of no relevance unless you are in a diagnostic situation.
Press ‘Exit’ in the middle section to return to the menu.
User
Press the ‘User’ button to view user data:
The 2 buttons at the left tell you the user name and user ID as determined by the router control
system. These are not the Windows user name or the panel ID.
 User names are important in lock, protect, and release situations. The user who “owns” a lock
or protect is identified by a user name.
Press ‘Exit’ on the right to return to the menu.
Panel Information
Press the ‘Panel’ button to view panel data:
The 5 buttons at the left tell you the panel ID, and other useful information about the panel, in
particular, the panel’s IP address. These are useful in a diagnostic situation. This information
helps configurers ensure that they are sending correct configuration file to the correct panel.
 The panel acquires its IP address through DHCP on the NV9000’s panel/router network.
BOOT BOOT
SV1133- SV1133-
000000 000000
APP APP
SV0000- SV0000-
000000 000000
SERVER SERVER
SV0921- SV0921-
06 06
EXIT EXIT
USER USER USER ID
USER ID
01 01
EXIT EXIT
PANEL ID PANEL ID
6482 6482
PANEL PANEL
NAME NAME
L648 L648
IP ADDR IP ADDR
192.168. 192.168.
104.214 104.214
SVR NAME SVR NAME L648
L648
EXIT EXIT
