Operation
Menu Mode
Note: because the NV9649 is in destination mode, the new destination mnemonic will immedi-
ately appear in the display of the intended control unit.
Procedure E — Takes Using Source Buttons
To perform a take to a single destination using a NV9648 control unit having standard source
buttons:
1 Press a source button in the control unit that corresponds to your intended destination.
The source becomes selected and the source button goes high-tally. The take button in the
same control unit goes high-tally red.
2 Press the take button. The take is completed.
Procedure F — Takes Using Quick Source Buttons
To perform a take to a single destination using a NV9648 control unit having quick source
buttons:
1 Press a quick source button in the control unit that corresponds to your intended destina-
tion.
2) That source is immediately taken to the destination of that control unit.
Menu Mode
The NV9648 enters menu mode if it has a menu button and you press the menu button.
 The menu is available only when the panel is operating under the LCD XY/MD model.
 The menu uses some of the buttons on your panel. The legends and functions of these
buttons in normal operating mode do not apply while the panel is in menu mode.
While the panel is in menu mode, you will use the menu button to cycle through the various
parts of the menu. This is the menu that appears when you press a menu button:
There are 4 parts:
• Software Versions
• User
• Panel Information
• LCD button illumination levels
Configurers should ensure that the menu button is not part of the numeric keypad that
becomes available in the panel submenu. See
Panel Information , following.
SOFTWARE SOFTWARE
VERSIONS VERSIONS USER
USER PANEL PANEL
LCD LCD
CONTROL CONTROL
EXIT EXIT
