User’s Manual of GS-4210-24P2S
4.5.6 Port VLAN Membership
This Page provides an overview of membership status for VLAN users. The VLAN Membership Status screen in
Figure 4-5-6
appears.
Figure 4-5-6:
Port VLAN Membership Table Page Screenshot
The page includes the following fields:
Object
Description
Port
The switch port number of the logical port.
Mode
Display the current VLAN mode.
Administrative VLANs
Display the current administrative VLANs.
Operational VLANs
Display the current operational VLANs.
Modify
Click
to modify VLAN membership.
