Viewing Data in Floating Point Format
Press [F] from the Database View menu. Use this command to display the data
on the current page in floating point format. The program assumes that the
values are aligned on even register boundaries. If floating-point values are not
aligned as such, they are not displayed properly.
Viewing Data in ASCII (Text) Format
Press [A] to display the data on the current page in ASCII format. This is useful
for regions of the database that contain ASCII data.
Viewing Data in Double Word Decimal Format
Press [L] to display the data on the current page in Double Word Decimal format.
This is useful for regions of the database that contain Double Word Decimal data.
Viewing Data in Double Word Decimal Format
Press [X] to display the data on the current page in Double Word Hexadecimal
format. This is useful for regions of the database that contain Double Word
Hexadecimal data.
Viewing DNP Binary Inputs
Press [1] to view a list of DNP Binary Inputs.
Viewing DNP Binary Outputs
Press [2] to view a list of DNP Binary Outputs.
Viewing DNP Counters
Press [3] to view a list of DNP Counters.
Viewing DNP Analog Inputs
Press [4] to view a list of DNP Analog Inputs.
Viewing DNP Analog Outputs
Press [5] to view a list of DNP Analog Outputs.
Viewing DNP Frozen Counters
Press [6] to view a list of DNP Frozen Counters.
Viewing DNP Float Inputs
Press [7] to view a list of DNP Float Inputs.
Viewing DNP Float Outputs
Press [9] to view a list of DNP Float Outputs.
