Smart Managed Pro Switches MS510TX and MS510TXPP
Monitor the System
User Manual
294
The following table describes the switch statistics displayed on the page.
Table 66. Switch statistics information
Field
Description
ifIndex
The interface index of the interface table entry associated with the processor of
this switch.
Octets Received
The total number of octets of data received by the processor (excluding framing
bits, but including FCS octets).
Unicast Packets Received
The number of subnetwork-unicast packets delivered to a higher-layer protocol.
Multicast Packets Received
The total number of packets received that were directed to a multicast address.
This number does not include packets directed to the broadcast address.
Broadcast Packets Received The total number of packets received that were directed to the broadcast
address. This does not include multicast packets.
Octets Transmitted
The total number of octets transmitted out of the interface, including framing
characters.
Unicast Packets Transmitted The total number of packets that higher-level protocols requested be transmitted
to a subnetwork-unicast address, including those that were discarded or not
sent.
Multicast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to a multicast address, including those that were discarded or not sent.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to the broadcast address, including those that were discarded or not sent.
Address Entries in Use
The number of learned and static entries in the Forwarding Database Address
Table for this switch.
Maximum VLAN Entries
The maximum number of VLANs allowed on this switch.
Static VLAN Entries
The number of active VLAN entries on this switch that were created statically.
View Port Statistics
The Port Statistics page displays a summary of per-port traffic statistics on the switch.
To view port statistics:
1.
Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2.
Launch a web browser.
3.
In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
The login window opens.
