◦ Change PIN - Press the Menu joystick towards the right to change the Bluetooth PIN
Background Color (RX only)- The Background Color feature allows you to select a screen color
displayed on the monitor when no video is received from the transmitter. This valuable tool indicates to
the crew that a signal has been dropped and the TX and RX need to be synced again.
Reset All Settings - Reset all configurable options to their factory settings.
Additional Information
Device Info - Displays the model and serial number of the device
Firmware Versions - Displays the current firmware versions for all device components.
Regulatory - Displays all compliance certifications and certification markings related to radio
frequencies used by the TX and RX to communicate. For complete regulatory information and
declarations of conformity, please visit the
Regulatory Information section.
Ranger Manager
Use the Ranger App to remotely manage and monitor every parameter of Ranger, including pairing,
frequency selection, and 3D LUTs.
CONNECT VIA BLUETOOTH
1. Download the Ranger App.
2. Enable Bluetooth on your iOS or Android device.
3. Navigate to the Bluetooth menu on both the transmitter and receiver, then select
Enable .
4. Open the Ranger App from your iOS or Android device, then tap the Status/Configuration button.
5. Select the device(s) you want to pair or monitor.
