Power and Connect
1. Attach the Ranger transmitter to your camera. If your Ranger (Mk II) TX is equipped with battery
plates, attach the unit to the back of your camera.
2. Connect power to the Ranger transmitter and receiver with the included A/C adapter, or if both
devices are equipped with battery plate accessories, attach a compatible battery (
Gold or V mount
).
3. Connect the output from your video source to either the SDI or HDMI input
(C or E)
on the Ranger
transmitter. Connect either the SDI or HDMI output
(D or J)
from the Ranger receiver to the video
input on your monitor.
NOTE: If mounting the receiver upright on a stand above the monitor, use a
right-angle SDI adapter to relieve any strain caused by the weight of the cable, and to avoid
damaging the SDI output’s internal connectors.
4.
Ranger Mk II Transmitter:
Attach the
H
and
V
barrel antennas to the type-N connectors on the
transmitter. The
V
antenna attaches to the V-connector, and the
H
antenna attaches to the H-
connector.
Ranger Micro Transmitter
: Attach two 2dBi antennas to the connectors on the transmitter. If using
an H+V antenna configuration, attach the H and V antennas to the connectors on the transmitter.
The V antenna attaches to the V-connector, and the H antenna attaches to the H-connector.
Ranger Mk II Receiver:
Attach the three 2dBi antennas to the receiver’s center connectors and the
two horizontal antennas to the left and right connectors.
Ranger Micro Receiver:
Attach five 2dBi antennas to the connectors on the transmitter. If using an
H+V antenna configuration, attach the three 2dBi antennas to the receiver’s center connectors and
the two horizontal antennas to the left and right connectors.
If using a Panel Antenna with the receiver
: Connect the receiver’s three center connectors to the
Array Antenna connections labeled “V,” then connect the left and right connectors to the “H”
connections using the RP-SMA connectors
).
NOTE: Ensure that the 2dBi
omnidirectional antenna (A) is attached at all times to the Panel Antenna when in use.
5. Move the power switches on both the transmitter and receiver (
I
)
to the
ON
position. Video appears
within a few seconds.
