frequency; the higher the bar, the more congested that frequency is. Make sure to always select the
shortest, least congested bar.

Status

- Displays the current status of:

TX Name

Quality

Network

Temperature

Link

Camera Recording

Video input

Bandwidth

Current frequency

Video output

Range

OSD name

Antenna Orientation

Ranger units require the use of external antennas for basic operation. For Ranger, we recommend

ONLY

using a Horizontal + Vertical (H+V) antenna configuration.

VERTICAL AND HORIZONTAL ANTENNAS

Vertical (V) antennas

are ideal for achieving diversity indoors and offer good performance in a wide

variety of short-to-medium range situations when quick setup and flexibility are key. Once you move
outdoors with the V antennas, the RF signals travel in a similar or identical manner toward the receiver,
weakening diversity.

Horizontal (H) antennas

were designed for use with the V antennas. H antennas

cause the RF signal from the transmitter to propagate perpendicularly compared to the vertical signal
from the V antenna. The

H+V antenna configuration

helps to maintain the quality and performance of

your video transmission, especially when your signal would otherwise begin to deteriorate due to noise
and/or longer ranges.

NOTE: H+V antennas must be attached to both the transmitter and receiver.

Teradek User Manual

Page 59

Ranger Micro | Mk II
