need to use either Launchpad or the Launchpad App. NOTE: Before starting either pairing process,
ensure that both the transmitter and receiver have the same firmware version and have Bluetooth
enabled.
PAIRING/UNPAIRING VIA FRONT PANEL
To Piar:
1. Using the Menu Joystick, navigate to the Pair menu on both the transmitter and the receiver front
panel.
2. Select Pair to begin the pairing process. The transmitter will begin scanning for a receiver within
range and automatically pair to the receiver.
3. Once paired, the front panel will indicate whether or not Pairing is successful.
To Unpair:
1. Navigate to the Unpair menu on either the transmitter and the receiver.
2. Select the transmitter/receiver you want to unpair. If you have multiple devices paired, you can select
Unpair All .
 PAIRING TIPS
If you’re having trouble getting units to pair, we recommend keeping the transmitter and
receiver six feet apart when pairing. Keep all other RF devices nearby turned off or out of range
to ensure the transmitter and receiver only detect each other. To eliminate any chance of
interference, perform the Wired Pairing process via Launchpad.
WIRED PAIRING VIA LAUNCHPAD
To Pair:
1. Connect both the transmitter and receiver(s) to your computer (Windows/Mac) via USB.
2. Open Launchpad, select the
Pairing tab, then tap the Wired Pairing button.
3. Select the devices you want to pair, then click the Pair Devices button. Launchpad will indicate
whether or not Pairing is successful.
To Unpair:
1. Connect both the transmitter and receiver(s) to your computer (Windows/Mac) via USB.
2. Open Launchpad, select the
Pairing tab, then tap the Unpair All button.
PAIRING VIA RANGER APP
To Pair:
1. Open the Ranger App from your iOS or Android device, then tap the Pairing button.
2. Select the transmitter you wish to pair, then tap the Next button.
3. Select the receiver(s) you wish to pair with the transmitter, then tap the Pair! button. The Launchpad
App will indicate when the pairing process is complete.
Teradek User Manual
Page 8 Ranger Micro | Mk II
