WIRELESS SETTINGS
USER SCENARIOS Band Broadcast Mode Fixed Frequency Bandwidth Video Quality (TX)
Longest Range
(No interference)
5GHz
Enabled w/
Panel Antenna
Optional 40MHz
Longer Distance
Mode
Long Range
(Busy RF)
6GHz Enabled Optional 40MHz
Longer Distance
Mode
Short Range 6GHz Optional Enabled 40MHz
Auto or
Best Quality Mode
Best Video Quality
(4K)
6GHz Disabled Optional 40MHz
Auto or
Best Quality Mode
Best Video Quality
(HD)
6GHz Disabled Optional 40MHz
Auto or Best/Better
Quality Mode
Multi-System*
(Close Range)
6GHz Disabled Enabled 20MHz
Better Quality
Mode
Multi-System*
(Mid Range)
6GHz Disabled Enabled 20MHz
Longer Distance
Mode
Multi-System*
(Short Range)
6GHz Optional Optional 40MHz Low Power Mode
* Multi-System scenarios refer to situations where multiple TX and RX paired systems are in use in
the same vicinity as the system you are trying to configure.
