◦ Figures below 30% indicate poor signal quality
◦ Figures between 30% and 45% indicate fair signal quality
◦ Figures above 45% indicate good signal quality
Spectrum Analyzer (RX Only) - The built-in Spectrum Analyzer provides a visual indication of channel
noise and saturation across the entire available frequency range. Move the Menu joystick left and right
to select a frequency. Frequencies are represented by bars; the higher the bar, the more congested that
frequency is.
Test Pattern (RX Only) - This menu allows you to select a video resolution format to output a test
pattern over HDMI or SDI. Select a specific output resolution from the resolutions list.
Advanced/System Settings
Lock Keypad - The Lock Keypad feature prevents the menu joystick from being used to avoid any
accidental or unauthorized configurations. There are two ways to lock the keypad:
• Navigate to Advanced Settings via the front panel and select Lock Keypad .
• Press and hold the menu joystick upward for 5 seconds.
To unlock, press and hold the menu joystick upwards for five seconds or until the display reads
"
KEYPAD UNLOCKED ."
HDMI (RX only) - Ranger supports all HDMI output modes. You can select from one of the following
options:
◦ Auto
◦ RGB 8bit
◦ RGB 10bit
◦ YCbCR 4:4:4 8bit
◦ YCbCR 4:4:4 10bit
◦ YCbCR 4:2:2 10bit
◦ YCbCR 4:2:0 8bit
◦ YCbCR 4:2:0 10bit
Audio (RX only) - Configure Ranger’s Audio settings. If Beep on REC is activated, you will hear a short
tone whenever the camera begins or stops recording. The Mute Settings allow you to completely mute
the audio or only mute audio while recording.
Bluetooth - Use the Bluetooth menu to enable or disable Bluetooth communication. NOTE: Bluetooth is
enabled by default.
◦ Enable Bluetooth - Allows transmitter and receiver to be paired and communicate with the
Launchpad App.
◦ Use Bluetooth PIN - Enables the use of a PIN for authentication when using the Launchpad App.
