Pairing/Unpairing

Ranger devices purchased as a set (TX and RX), are paired by default, requiring no additional
configuration. Ranger devices purchased separately need to be paired using the device's front panel
(OLED) menu,

Launchpad

, or

Ranger Manager

. To pair your transmitter with multiple receivers, you will

need to use either Launchpad or

Ranger Manager

NOTE: Before starting either pairing process, ensure

that both the transmitter and receiver have the same firmware version and have Bluetooth enabled.

PAIRING/UNPAIRING VIA FRONT PANEL
To Pair:

1. Using the Menu Joystick, navigate to the

Pair

menu on both the transmitter and the receiver front

panel.

2. Select

Pair

to begin the pairing process. The transmitter will begin scanning for a receiver within

range and automatically pair with the receiver.

3. Once paired, the front panel will indicate whether or not Pairing is successful.

To Unpair:

1. Navigate to the

Unpair

menu on either the transmitter or the receiver.

2. Select the transmitter/receiver you want to unpair. If you have multiple devices paired, you can select

Unpair All



PAIRING TIPS

If you’re having trouble getting units to pair, we recommend keeping the transmitter and
receiver six feet apart when pairing. Keep all other RF devices nearby turned off or out of range
to ensure the transmitter and receiver only detect each other. To eliminate any chance of
interference, perform the Wired Pairing process via Launchpad.

WIRED PAIRING VIA LAUNCHPAD
To Pair:

1. Connect both the transmitter and receiver(s) to your computer (Windows/Mac) via USB.
2. Open Launchpad, select the

Pairing

tab, then tap the

Wired Pairing

button.

3. Select the devices you want to pair, then click the

Pair Devices

button. Launchpad will indicate

whether or not Pairing is successful.
