KBF / KBF P (E5.3) 09/2014 page 65/110
Check the setting regularly and adjust it following changes of the set-point or charge.
11. Notification and alarm functions
11.1 Notification and alarm system overview (auto diagnosis system)
The unit provides notification and alarm functions, which indicate messages in up to three steps:
1. Visual indication of notifying or error messages are blue notes on the display of the MB1 controller.
2. Visual indication of alarm messages are red notes with an alarm bell symbol. After a delay time, some
notes change their color from blue to red.
In addition, there is an audible alert, if you did not deactivate the buzzer in the “User level” menu
(chap. 6.4).
3. Zero-voltage relay outputs (option, chap. 15.5) allow transmitting the alarm e.g., to a central monitor-
ing system.
Notifying sequence 1 2 3
Event Note
(blue field)
Alarm
(red field)
Zero-voltage
relay alarm out-
puts (option)
Error of the humidity system. Press
RESET key for further information.
HUMID SYSTEM
immediately
HUMID SYSTEM
after 1 min.
Notification or error of the humidity
system.
For detailed information see chap.
11.2.
HUMID SYSTEM
(notification flashes)
Temperature deviation of more than
+/- 2 °C of the entered set-point
TEMP RANGE
immediately
TEMP RANGE
after 16 min.
after 16 min.
Humidity deviation of more than +/- 5
% r.H. of the entered set-point
HUMID RANGE
immediately
HUMID RANGE
after 16 min.
after 16 min.
Exceeded temperature limit of the
safety controller
TEMPERATURE LIMIT
immediately
Humidity system turned off with
switch (4)
HUMID OFF
immediately
Door open
DOOR OPEN
immediately
DOOR OPEN
after 5 min.
Power failure immediately
With option temperature safety device class 3.3 (chap. 10.3):
Exceeding the maximum or minimum
temperature
TEMP ALARM
immediately
With option locking of the keyboard (BINDER Individual, chap. 15.7):
Locked keyboard
KEY LOCK
immediately
The indicated intervals refer to the time after occurrence of the error or notified condition.
