19
Working
Humidity 10%－90%
Air
Pressure 86kpa－106kpa
Dimension 325(W) x245 (D) x45mm( H)
Weight 1.25KG(Exclude HDD)
Installation
Mode Desktop installation
1.3.10 Econimic 720P(V2) Mini 1U Series
Parameters 4-Ch 8-Ch 16-Ch
System Main Processor Industrial embedded micro controller
OS Embedded LINUX
Video
Parameters Video Encode
Standard
H.264
Encode
Resolution 720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Frame
Rate
1536Kbps-4096Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps
Bit Stream Type Video stream/composite stream
Dual-Stream Support
Audio
Parameters Encode
Standard G.711A/G.711U/PCM
Audio Sampling
Rate 8KHz，16Bit
Audio Bit Rate 64Kbps
Video Port Analog Video
Input
4-channel ， BNC
port 8-channel ， BNC
port 16-channel ， BNC
port
Network Video
Input
N/A
Video Output 1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output N/A
Matrix Output N/A
Audio Port Audio Input N/A
Audio Output N/A
Bidirectional
Talk Input N/A
Record Record Mode Schedule record/manual record/MD record/Alarm record
Record
Playback Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode HDD, burner, USB device, network backup
Alarm Alarm Input N/A
Alarm Output N/A
HDD HDD Port 1 SATA port，does not support eSATA port
One HDD
Space
4T
Coomunication
Port Network 1 RJ45 port, 100Mbps Ethernet port
Communication RS485 port
USB 2 USB ports
