26
Parameters 4-Ch 8-Ch
Rate
Video Frame
Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps
Bit Stream Type Video stream/composite stream
Dual-Stream Support
Audio
Parameters Encode
Standard G.711A/G.711U/PCM
Audio Sampling
Rate 8KHz，16Bit
Audio Bit Rate 64Kbps
Video Port Analog Video
Input
4-channel，BNC port 8-channel，BNC port
Network Video
Input
N/A
Video Output 1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output N/A
Matrix Output N/A
Audio Port Audio Input N/A
Audio Output N/A
Bidirectional
Talk Input N/A
Record Record Mode Schedule record/manual record/MD record/Alarm record
Record
Playback Max 4-channel playback Max 8-channel playback
Backup Mode HDD, burner, USB device, network backup
Alarm Alarm Input N/A
Alarm Output N/A
HDD HDD Port 1 SATA port，does not support eSATA port
One HDD
Space
4T
Coomunication
Port Network 1 RJ45 port, 100Mbps Ethernet port
Communication RS485 port
USB 2 USB ports
Others Power DC12V
Power
Consuption ≤30W（With power adapeter, no HDD）
Working
Temperature -10℃－＋55℃
Working
Humidity 10%~90%
Dimensions Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight 1.25KG（No HDD）
Installation
Mode Desk
1.3.15 Advanced 1080P (V2) Mini 1U Series
Parameters 4-Ch 8-Ch
System Main Processor Industrial embedded micro controller
