HP ProCurve Switch Rack specifications
Use the following specifications to determine load, spacing, power, and other factors when planning
system racks.
Table 1: Mechanical specifications
Specification Characteristic
Rack-mount Cabinet Type
1 Rack units
443 (w) x 44 (h) x 392 (d) mm External Dimensions
Maximum 7 kg Weight
Table 2: Power specifications
Specification Characteristic
100-127 VAC/200-240 VAC; 50/60 Hz Type
4.0/2.0 A, 200W Power Consumption
Dell R620 Rack specifications
Use the following specifications to determine load, spacing, power, and other factors when planning
system racks.
28 GV STRATUS Installation and Service Manual 2013 12 19
Commissioning a system
