Input signal 4:3 monitor Output signal 16:9 monitor
16:9 Letterbox image in 4:3 frame
(4:3_10)
16:9 Letterbox image in 4:3 frame
(4:3_10)
16:9 Full frame image in a 16:9 frame
(16:9_8)
14:9 Letterbox image in a 4:3 frame
(4:3_11)
14:9 Letterbox image in a 4:3 frame
(4:3_11)
14:9 Pillar-box image in a 16:9 frame
(16:9_11)
4:3 Image shoot and protect 14:9 in a
4:3 frame
(4:3_13)
4:3 Image shoot and protect 14:9 in a
4:3 frame
(4:3_13)
14:9 Pillar-box image in a 16:9 frame
( 16:9_11)
16:9 Letterbox image shoot and
protect 14:9 in a 4:3 frame
(4:3_14)
16:9 Letterbox image shoot and
protect 14:9 in a 4:3 frame
(4:3_14)
16:9 Image shoot and protect 14:9 in a
16:9 frame
(16:9_14)
16:9 Letterbox image shoot and
protect 16:9 in a 4:3 frame
(4:3_15)
16:9 Letterbox image shoot and
protect 16:9 in a 4:3 frame
(4:3_15)
16:9 Image shoot and protect 14:9 in a
16:9 frame
(16:9_15)
16:9 image shoot and protect 16:9 in a
4:3 frame (anamorphic)
(16:9_8)
16:9 image shoot and protect 16:9 in a
4:3 frame (anamorphic)
(16:9_8)
16:9 Full frame image in a 16:9 frame
(16:9_8)
