GUIDE TO INSTALLATION AND OPERATION
2 | Kaleido-Solo
1.2 Key features and benefits

3Gbps/HD/SD to HDMI converter for video and audio monitoring

Offers high quality and rich monitoring using a low-cost LCD panel

Dual program loudness and dialnorm monitoring over time (KS-910 only)
o Enhanced loudness measurements
o EBU R128
o ATSC A/85 ITU BS.1770-1
o ATSC A/85 ITU BS.1770-2
o ATSC A/85 ITU BS.1770-3
o ARIB TR-B32
o Full-screen layout
o Loudness configurable alarm threshold
o Offline capture automation (EOM/SOM)
o Optional logging capabilities via iControl or iControl Solo
o Measure from internal down mix processing

Automatic input format detection

Supports 525i, 625i, 720p, 1080i and 1080p video resolutions

Multi frame rate support including 23.98p/PsF, 24p/PsF, 25p/PsF, 50i, 50p,
59.94i and 59.94p

Built-in scaler/de-interlacer

Optical SFP fiber input/output options

S/PDIF digital audio terminal that can output either:
o a 5.1 Downmix
o any PCM stereo pair
o an incoming Dolby Digital stream

Analog audio terminal that can output either:
o a 5.1 Downmix
o any PCM stereo pair

Selectable burn-in and Metadata overlay:
o History graph of audio loudness levels and dialnorm
o ALM (Audio level, phase and peak meters)

Can display from Dolby E (KS-910 only)

Can display from internal down mix (KS-910 only)
o Time Code
o AFD/WSS/VLI

Customisable names
o Aspect ratio markers
o Dynamic UMD (Under Monitor Display) and Tallies
o Subtitling (608, Legacy 608, 708, Teletext, OP-47)
o V-CHIP/CAD

Menu navigation through web browser

Monitor power saving mode

Configurable presets

Configurable general purpose input/output (GPIO)

Automatic aspect ratio support

Video scaling and positioning options

HDMI 5.1 audio support

Easy configuration using on-screen menus

Failsafe mechanism for unsupported monitor resolutions

Convenient mounting bracket included

Optional remote control for menu navigation and configurable buttons
