GUIDE TO INSTALLATION AND OPERATION
62 | Kaleido-Solo
Description
Scale
Scale is the graduation in dB of an audio level meter.
Channel ID
Identifies the audio channel pair reprensented by audio level meter.
Phase meter
Provides an indication of the relative phase of the two channels and thereby provides some
measure of mono compatibility. The range is 0 to 180 degrees and is represented as follows:
bottom is 0 degrees and top is 180 degrees.
Channel
assignment
Provides the channel assignation only where there is valid extracted Dolby metadata (see section
5.3.3).
