GUIDE TO INSTALLATION AND OPERATION
22 | Kaleido-Solo
5.3.2 Metadata - Timecode
Status
Time Code
Status:
Time code status shows the presence of time code (Detected or N/A).
SD Select Mode
Select whether time code extraction from SD video inputs will be automatic or manual.
Auto:
The vertical interval of the incoming video is scanned and the first detected time code is extracted.
Manual:
Time code will only be extracted if it appears on a specified line in the vertical interval.
In Manual mode only, the SD Select Line menu item is enabled, allowing the line number for extraction to be
specified.
HD Select Type
Select the source of the timecode to be displayed when the input video is HD.
VITC:
Use ATC VITC time code (time code updated every field).
LTC:
Use ATC LTC time code (time code updated every frame).
